| Model | DHY1 | DHY1.5 | DHY2 | DHY3 | DHY5 | DHY10 | DHY20 | |
| Rated Load | Ton | 1.00 | 1.50 | 2.00 | 3.00 | 5.00 | 10.00 | 20.00 |
| Test Load | Gn | 1.5Gn | 1.5Gn | 1.5Gn | 1.5Gn | 1.25Gn | 1.25Gn | 1.25Gn |
| Power | kw | 0.30 | 0.30 | 0.30 | 0.75 | 0.75 | 0.75 | 0.75 |
| Switch Type | Defence Rain Switch | |||||||
| Voltage | 380V 50HZ | |||||||
| Lifting Speed m/min | m/min | 2.00 | 2.00 | 2.00 | 1.00 | 1.00 | 0.46 | 0.46 |
| Min Distance of Two Hook | mm | 270.00 | 350.00 | 380.00 | 470.00 | 600.00 | 700.00 | 1000.00 |
| No. of lifting chain | 1.00 | 1.00 | 2.00 | 2.00 | 2.00 | 4.00 | 8.00 | |
| Lifting Chain Dia. | mm | 6.00 | 8.00 | 6.00 | 8.00 | 10.00 | 10.00 | 10.00 |
| N.W. | kg/pc | 26.00 | 32.00 | 30.00 | 37.00 | 54.00 | 88.00 | 195.00 |
| G.W. | kg/pc | 28.00 | 34.00 | 32.00 | 42.00 | 66.00 | 102.00 | 235.00 |
| Weight Add of One Meter | kg | 0.84 | 1.46 | 1.67 | 2.92 | 4.52 | 9.04 | 18.80 |
